DOUBLE-SIDED BONDING · ACRYLIC
Acrylic adhesive tape for durable bonds
Acrylic adhesive tape is an option for durable industrial bonds. The range includes acrylic foam tapes; selection depends on the substrates, tape construction and actual load.
01
Subcategory
3M Acrylic Adhesive Tape
02
Selection criteria
Select acrylic tape by construction and substrate
Start with both bonding surfaces: material, coating and surface energy affect adhesion. Then consider thickness, construction and the direction and duration of the load. An acrylic foam core can conform to surfaces and absorb stress between unlike parts; suitability always depends on the specific tape and application.
03
Acrylic adhesive tapes
Acrylic adhesive tapes in the range
The listing shows the product variants assigned to this category. Check each item's adhesive, foam core, thickness and suitability for your substrates.
Double-sided tape
Iguna CL - Clear acrylic foam - 0.5 mm thickness - 500 mm x 33 m
Double-sided tape
Iguna CL - Clear acrylic foam - 1.0 mm thickness - 500 mm x 33 m
Double-sided tape
Iguna CL - Clear Acrylic Foam - 2.0 mm Thickness - 500 mm x 16.5 m
Double-sided tape
Iguna CL - Clear Acrylic Foam - 3.0 mm Thickness - 500 mm x 5 m
Double-sided tape
Iguna HS - High Standard Acrylic Foam - 0.4 mm Thickness - 900 mm x 33 m
Double-sided tape
Iguna HS - High Standard Acrylic Foam - 0.64 mm Thickness - 900 mm x 33 m
Double-sided tape
Iguna HS - High Standard Acrylic Foam - 0.8 mm Thick - 900 mm x 33 m
Double-sided tape
Iguna HS - High Standard Acrylic Foam - 1.2 mm Thickness - 900 mm x 33 m
Double-sided tape
Iguna HT - High Temperature Acrylic Foam - 0.8 mm Thickness - 900 mm x 33 m
Double-sided tape
Iguna HT - High Temperature Acrylic Foam - 1.2 mm Thickness - 900 mm x 33 m
Double-sided tape
Iguna LS - Low Surface Acrylic Foam - 0.64 mm Thickness - 900 mm x 33 m
Double-sided tape
Iguna LS - Low Surface Acrylic Foam - 0.8 mm Thickness - 900 mm x 66 m
Double-sided tape
Iguna LS - Low Surface Acrylic Foam - 1.1 mm Thickness - 900 mm x 33 m
3M VHB
3M VHB Klebeband 4915, Transparent, 63 mm x 102 mm, 1.5 mm, Stanzteil
3M Double-Sided Adhesive Tape
3M Acrylic Foam doppelseitiges Klebeband GT5912TY, grau, 1.2 mm, 300 mm x 50 m
3M Double-Sided Adhesive Tape
3M Acrylic Plus doppelseitiges Klebeband EX4008, Schwarz, 0.8 mm, 600 mm x 66 m
No products match this combination.
No products match all of the selected filter criteria.
04
Choosing acrylic adhesive tape
Distinguish acrylic adhesive from acrylic foam
Acrylic identifies the adhesive chemistry; acrylic foam describes one possible tape core. In 3M Acrylic Foam 5361, the core is acrylic foam and one side has an additional acrylic adhesive layer. Do not treat every tape with acrylic adhesive as acrylic foam. To narrow down the choice, specify both substrates, the required bond, load direction and service conditions. Krückemeyer GmbH can assess suitable variants and convert an appropriate tape into cut widths or die-cut parts for your process.
05
Acrylic adhesive tape questions
What does acrylic mean in double-sided adhesive tape?
Acrylic identifies the adhesive chemistry, not necessarily the entire tape construction. A tape may also have a carrier or an acrylic foam core. In 3M Acrylic Foam 5361, an acrylic foam core has an additional acrylic adhesive layer on one side. Selection therefore depends on which layer bonds to each substrate and how the complete construction behaves under the intended load.
How does acrylic foam differ from a tape with acrylic adhesive?
Acrylic foam forms a viscoelastic tape core; acrylic adhesive is an adhesive layer. In 3M Acrylic Foam 5361, one side of the foam core has an additional acrylic adhesive layer. The core can absorb stress in the bond line and conform to the bonding surfaces. This is not a general property of every acrylic adhesive tape. Compare the actual construction, substrates and required load for your application.
Which substrates suit acrylic adhesive tape?
That depends on the adhesive formulation and the two actual bonding surfaces. For 3M Acrylic Foam 5361, many automotive paints and certain medium-surface-energy substrates may be suitable; this does not mean the tape suits every plastic. Tell us the material, coating and surface condition of each part. On demanding substrates, assess suitability and any surface preparation on the actual component.
What information is needed for a converted tape format?
Start with the intended result and both bonding surfaces. For converting, also specify the required tape width or shape, delivery format and application step. Krückemeyer GmbH can cut suitable starting material or supply it as die-cut parts. Whether the selected acrylic adhesive tape will support the bond under your service conditions needs to be assessed for the material and application.
06
Request advice
Describe the substrates, load and required tape format. Krückemeyer GmbH's bonding team can help assess a suitable variant and possible converting options.
Discuss acrylic tape for your application
Tell us about your substrates, load and preferred delivery format. We can assess a suitable tape variant and converting approach.
Acrylic adhesive tape advice
Thomas Klein
Contact for products
Discuss your substrates, planned load and suitable tape format with Thomas Klein.
